芯盒类型/ADF Selet: TH-1/TH-2
暗态色号/Dark State: DIN9-13/DIN5-14/DIN9-12
亮态色号/Light State: DIN4
开关时间/Switching Time: <1/25,000s(0.00004s)
视窗尺寸/Viewing Area: 96 X 60mm/91X 42mm
芯盒尺寸/Cartridge Size: 114X 133X 10mm
灵敏度/Sensitivity:无极调节Stepless Adjustment
返回时间/Delay Time: 0.3~0.7s无极调节Stepless Adjustment
电池/Battery:可更换锂电池、太阳能电池(工作时间大于5000小时)
Replaceable Li-Mi & Solar Combination
(Min.lifetime:5000 Welding Hours)
操作温度/Operation Temperature:-5° C (23° F)-55° C (131° F)
紫外线透过率/UV Transmittance: 313nm≤0.00006% 365nm≤0.00006%
红外线透过率/ IRTransmittance: 780-1300nm≤0.0003%
1300-2000nm≤0.0009%
重量/Weight:550g(1.21 Pound)
头盔材料/Material of Helmet:尼龙Nylon
保护镜片/Cover Lens: CR-39/PC
